Part Number	Package	VRWM	IR max	VBR min	VBR max	Ipp	VC max	Ppp	Data Sheet

Part Number	Package	(V)	(uA)	(V)	(V)	(A)	(V)	(W)	Data Sheet
SODJ Series	SOD-123FL	5.0~440	1.0~800	6.4~224	7.07~247	0.62~21.74	9.2~324.0	200
SOD4J Series	SOD-123FL	5.0~200.0	1.0~800	6.4~224	7.07~247	1.2~43.5	9.2~324.0	400
SMDJ Series	DO-214AB/SMC	5.0~440	2.0~800	6.4~492	7.0~543	4.21~326.09	9.2~713	3000
SMCJ Series	DO-214AB/SMC	5.0~440	1.0~1600	6.4~492	7.0~543	2.1~163.04	9.2~713	1500
SMBJ Series	DO-214AA/SMB	5.0~440	1.0~1600	6.4~492	7.07~543	0.84~65.22	9.2~713	600
SMAJ Series	DO-214AC/SMA	5.0~440	1.0~1600	6.4~492	7.07~543	0.56~43.48	9.2~713	400
SMAFJ Series	SMAF	5.0~200.0	1.0~1600	6.4~224	7.07~247	1.85~65.22	9.2~324.0	400
SMAF6J Series	SMAF	5.0~200.0	1.0~1000	6.4~224	7.07~247	1.85~65.22	9.2~324.0	600
SMA6J Series	DO-214AC/SMA	5.0~200.0	1.0~1000	6.4~224	7.07~247	1.85~65.22	9.2~324.0	600
SM8S Series-HM	DO-218AB	10~85	10~15	11.1~94	12.8~104	48.2~388	17~137	6600
SM8K Series	DO-218AB	18~40	10	20~44.4	23.3~51.1	124~274	29.2~64.5	8000
SM5S Series	DO-218AB	15~54	10	16.7~60	19.2~69	41~148	24.4~87.1	3600
SA Series	DO-15/D0-204AC	5.0~180	5~600	6.4~200	7.0~233	1.7~55.4	9.2~289	500
P6SMB Series	DO-214AA/SMB	5.8~495	1.0~1000	6.45~522.5	7.14~577.5	0.8~57.1	10.5~760	600
P6SMA Series	DO-214AC/SMA	5.8~495	1.0~1000	6.45~522.5	7.14~577.5	0.8~57.1	10.5~760	600
P6KE Series	DO-15	5.8~467	1.0~1000	6.45~522.5	7.14~577.5	0.8~57.1	10.5~760	600
P4SMA Series	DO-214AC/SMA	5.8~467	1.0~1000	6.45~522.5	7.14~557.5	0.5~39	10.5~760	400
P4KE Series	DO-41	5.8~467	1.0~1000	6.45~522.5	7.14~557.5	0.5~39	10.5~760	400
15KP Series	R6(P600)	17~280	5~5000	18.99~312.8		33.2~515.4	29.3~454.5	15000
8KP Series	R6(P600)	28~170	1.0	31.1~189	34.4~209	29~176	45.4~275	8000
5KP Series	R6(P600)	5.0~250	5~50	6.4~277	7.0~306	12~554.3	9.2~425	5000
5.0SMDJ Series	DO-214AB/SMC	11~170	5~800	12.2~189	13.5~209	18.2~274.7	18.2~275	5000
3KP Series	R6(P600)	5.0~250	5~50	6.4~277	7.0~306	7.05~326.1	9.2~425	3000
1.5SMC Series	DO-214AB/SMC	5.8~459	1.0~10	6.45~513	7.14~569	2.0~143	10.5~740	1500
1.5SMBJ Series	DO-214AA/SMB	5.0~220.0	1.0~1600	6.4~246.0	7.0~272.0	4.2~163.04	9.2~356.0	1500
1.5KE Series	DO-201AD	5.8~467	1.0~1000	6.45~522.5	7.14~577.5	2.0~143	10.5~760	1500
1.0SMBJ Series	DO-214AA/SMB	5.0~200.0	1~1600	6.4~224.0	7.0~247.0	3.08~108.7	9.2~324.0	1000
