2/3-Axis Accelerometers
MiraMEMS’2/3-axis accelerometers are based on the principle of capacitance change during a directional acceleration to convert the mechanical motion into an electrical signal. Using the proprietary 3D CMOS–MEMS integration technology, MiraMEMS’accelerometers deliver high resolution up to 14 bit, low power consumption and programmable interrupts.

P/N	FIFO	Pedometer	Resolution	Package Size	Pins	Ultra Low Power	AEC-Q100
da270	32-level	yes	14	2 x 2 x 1.1mm	LGA 12	YES	NO
da217	32-level	yes	14	2 x 2 x 0.9mm	LGA 12	NO	NO
da215	no	no	14	2 x 2 x 0.9mm	LGA 12	NO	NO
da213B	no	no	14	2 x 2 x 1.1mm	LGA 12	NO	NO
da218B	no	no	12	2 x 2 x 0.9mm	LGA 12	NO	NO
da262	32-level	yes	14	2 x 2 x 0.9mm	LGA 12	YES	NO
da312B	no	no	14	3 x 3 x 0.9mm	LGA 16	NO	NO
da380B	no	no	14	3 x 3 x 0.9mm	LGA 10	NO	NO
dva290	32-level	no	14	2 x 2 x 0.9mm	LGA 12	YES	YES

3-Axis Magnetometer
3-axis magnetometer are based on the principle of hall effect. It integrates SPI/I2C control interface. MiraMEMS’ 3-axis magnetometer delivers 16 bit high resolution, temperature compensation, single/burst measure, wake-upon change mode  .

Title	Axis	G-range	Sensitivity	Noise	Resolution	Package Size	Pins
3-Axis Magnetometer   dm110	3	±48gauss			16bit	2mm*2mm*0.75mm	16
3-Axis Magnetometer   dm211	3	±48gauss			16bit	2mm*2mm*0.75mm	16

6-Axis A+M Combo
Integrating a 3-axis accelerometers and a 3-axis magnetometer, 6-axis A+M combo can deliver the function of electronic compass. The combo has excellent noise density index, and is pin compatible to MiraMEMS’2x2 accelerometer product, giving potential customers an easy path to upgrade from a 3-axis accelerometer solution to a 6-axis A+M combo solution.

Title	Axis	G-range	Sensitivity	Noise	Resolution	Package Size	Pins
6-Axis A+M Combo  dc213	6	±2g/±4g/±8g/±16g	4096/2048/1024/512 (LSB/g)	150(ug/sqrt)	14bit/8bit	2mm*2mm*1.1mm	12

9-Axis Soft GYROSCOPE

MiraMEMS can provide software algorithm of a gyroscope, with an output frequency up to 64 Hz, and a resolution of 1 deg/S, 60 ms delay. MiraMEMS’ 9-axis soft gyroscope solution delivers low power consumption, which is only a fraction of a traditional 9-axis combo. Using 6-axis A+M combo with soft gyro algorithm, one can achieve many functions originally implemented by 9-axis combo, for example the indoor navigation.

Intelligent Motion Sensor

MiraMEMS’intelligent motion sensor is an open architecture solution, integrating a 8-bit MCU with embedded 16K ROM and 1K Static-RAM and a 3-axis accelerometer. The solution comes with a set of code development tools, including the integrated development environment (IDE). Open architecture’s excellent extensibility and sensor data integration capabilities allow the local processing to reduce the loading of main chip. To help speed up the product development, MiraMEMS also provides a software library suite. This suite includes highly accurate pedometer algorithm and algorithm with anti-noise filters, and sleep monitoring algorithm. Open architecture of programmable algorithm provides the possibility for subsequent multiple sensor, including fall detection, 6D orientation implementation.

GYROSCOPES

MiraMEMS gyroscope will be launched in 2016.
